VELFAC Ribo wood/aluminium - Sidehung window

Available as single leaf or double leaf with French Casement or rebated meeting style.
The sash stops just below 90°.
Visible hinges.
Available as 32mm double and 52mm triple glazing.

Standard fittings

An espagnolette handle, which has a ventilation position in the striking plates when the frame height is above 530mm).
A handle operated brake, which can keep the window open in a random position under calm weather conditions (however, below width <426mm or height <530mm only with friction arm).
A sash lift pulley wheel to support and assist the functionality of the sash, and which must be activated during installation of the door.
2-leaf elements have a standard espagnolette in the master sash and an espagnolette with safety-lock in the slave sash.
