VELFAC 200 ENERGY Top-guided window
- When opened the sash provides a ventilation gap at the head.
- Available as 48mm triple glazing.
Standard fittings
- An espagnolette handle, which has a ventilation position in the striking plates.
- The adjustable friction arms can hold the window open under calm weather conditions.
- Friction arms and U-shaped glide-rails are made of steel with a grey zinc-aluminium surface treatment.
- Windows >1400mm are fitted with circular catch handles on both sides to ensure wind and water tightness.
Alternative fittings
Windows lower than 490mm or slimmer than 370mm are supplied with circular catch handle and friction arm, not with espagnolette handle.
If a rescue opening is required in very low windows it is recommended to use VELFAC 200 ENERGY tophung window.
Min./max. & free opening sizes - topguided window
Min./max. sizes
Minimize
Standard fittings
Espagnolette, standard
Friction arm
Ventilation position
Options & Accessories
Espagnolette with safety-lock
Espagnolette with lock
Espagnolette for cylinder lock
Lockable restrictor (160mm or 270mm)
VELFAC maxi-handle
Circular catch handle
_crop.jpg?width=212&height=212)
Acoustic trickle vent
Click vent
WindowMaster motor for Natural Ventilation
Restrictor with ventilation position
